Rampart Welded Wire
When it comes to form and function Rampart Welded Wire has you secured. Cutting through welded mesh is time-consuming and difficult. Rampart Welded Wire adds beauty and elegance to every property it protects.
Rampart 354 - Security Fencing
RAMPART 354 panels provide the highest level of security. The small mesh size combined with additional horizontal double wires ensure a strong and rigid panel.
Recommended Application
- Airports
- Jails/Prisons
- High risk areas
Technical Specifications
| Technical Data | Rampart 354 Specification |
|---|---|
| Mesh Opening | 3" x .5" (76.2 mm x 12.7 mm) |
| Gauge of Horizontal Wire | 2 x 8 GA (4 mm) Extra wire every 6" |
| Gauge of Vertical Wire |
1 x 4 GA (6 mm) |
| Standard Height | 4', 6', 8' (1248.4 mm, 1858 mm, 2467.7 mm) |
| Standard Length | 8'3" (2518 mm) |
| Finish | Galvanized; Powder Coat |
Downloads
- Rampart Welded Wire - Brochure (PDF 0.3MB)
- Rampart 354 - Panel Drawing (PDF 0.1MB)
- Rampart 354 - Spider Bracket Drawing (PDF 0.2MB)
- Rampart 354 - Panel CAD Drawing 1 of 1 (DWG 0.6MB)
- Rampart 354 - Defender Bracket CAD Drawing 1 of 1 (DWG 1.2MB)
- Rampart 354 - Defender Bracket Drawing (PDF 0.1MB)
- Rampart 354 - Spider Bracket CAD Drawing 1 of 1 (DWG 6.8MB)
